Y-coupling reduced 8 - 10

Not rated

80 Kč –10 %

Tip

80 Kč –10 % 72 Kč / pcs 60 Kč excl. VAT

454 pcs

Set up a watchdog

In store 78 pcs

External warehouse 376 pcs

We deliver to:

09.04.2025

Delivery offer

pcs

Y-socket for quick fitting of 8 mm diameter plastic tubing with 10 mm reduction. Designed especially for automation, measuring and control technology and pneumatic compressed air distribution in industry, engineering and automotive technology. Maximum working temperature in the range -10/+60 °C and pressure 10 bar.

Detailed information

Add to comparison

Code: PW-810

Brand: Pneumatics & Hydraulics

Add to inquiry

Free shipping

For purchases over 5,000 CZK

We guarantee

Extended warranty and service

Discount voucher

For every purchase

Return of goods within 30 days

Completely at our expense

Technical parameters

Y-coupling for easy installation of 8 mm tubing with reduced 10 mm outlet

Socket couplings with reduced dimensions and weight, for quick and easy assembly of plastic tubing
Materials used: nylon, polyurethane and nickel-plated brass MS 58, threads with Teflon coating or O-ring sealing
Designed especially for automation, measuring and control technology and pneumatic compressed air distribution in industry, engineering and automotive technology

Product is included in the following categories: Fasteners Plastic socket couplings Y-connector

Technical parameters

Category:	Y-joint reduced
Pressure:	10 bars
A tube:	8 mm
Material:	Brass, PU
Medium:	Compressed air
Working temperature:	-10 / +60 °C
Reducing:	10 mm
Width:	29 mm
Connection system:	Plug-in system

Produktový list
(728.9 kB)
