Cast iron WK430A aggregate on base frame příkon 2,2 kW, sací výkon 420 l/min, tlak 10 bar, napětí 230/50 V/Hz
Code: WK430A-PLATERelated products
Product detailed description
Walter WK430A-PLATE - Single-phase compressor unit for universal use
The Walter WK430A-PLATE is a compact reciprocating compressor unit with a two-cylinder cast iron block that offers high performance and durability with a single-phase 230 V supply. This model is supplied without a pressure vessel, allowing it to be used as a replacement compressor block or as part of its own air system. Its robust design, low running costs and easy maintenance make it ideal for workshops, garages and smaller industrial applications.
🔧 Technical specifications
- Power: 2.2 kW (3 HP)
- Power supply: 230 V (single-phase)
- Suction power: 430 l/min
- Discharge: 340 l/min
- Maximum pressure: 10 bar
- Number of cylinders/stages: 2/1 (two-cylinder single-stage unit)
- Noise level: ~80 dB(A)
- Airbox: ❌ without airbox (unit on frame)
- Weight: ~35 kg
✅ Benefits for customers
🔹 S ingle-phase power supply (230 V) - allows use where three-phase power is not available.
🔹 Cast iron two-cylinder aggregate - guarantees long life and high durability.
🔹 Low speed (~1300 rpm) - less mechanical stress, quieter operation and longer life.
🔹 Easy installation - suitable for incorporation into your own system or as a replacement for an older compressor.
🔹 Economical operation - low operating costs, low maintenance.
🚀 Modernization and innovation
The WK430A-PLATE uses the latest generation of the WK 430 piston unit, which has undergone an extensive upgrade:
✅ More precise component manufacturing - reduced oil vapor in compressed air, longer seal life.
✅ Improved suction filter with metal insert - more efficient intake air filtration, longer maintenance intervals.
✅ Reinforced piston rings and valves - higher reliability under long-term load.
✅ More durable bleeder valves - minimise oil mist leakage into the breather.
✅ Steel filter cover - protects the filter from mechanical damage and prolongs its life.
🏭 Ideal use
The Walter WK430A-PLATE is ideal for plants that do not have access to three-phase power but need a powerful and durable compressor unit.
✔ Car repair shops and tire shops - operation of pneumatic tools, paint guns.
✔ Craft and locksmith workshops - pneumatic tool drive, blowing, compressed air cleaning.
✔ Replacement unit - suitable for replacing the existing compressor block in air systems.
✔ Installation companies and construction sites - use in places where only 230V is available.
Additional parameters
Category: | Compressors for all applications - hobby and industrial |
---|---|
Warranty: | 2 years |
Compressor type: | Piston compressor |
Pressure: | 10 bars |
Suction power: | 430 l/min |
Displacement: | 340 l/min |
Pressure vessel volume: | It isn't |
Motor power: | 2.2 kW |
Mains voltage: | 230/50 V/Hz |
Speeds: | 1,276 rpm |
Number of cylinders: | 2 |
Number of grades: | 1 degree |
Lubrication: | Oily |
Noise: | 80dB(A) |
Dimensions: | 610 x 380 x 380 mm |
Weight: | 41 kg |
Engine: | Electric |
Soundproofed: | No |
Drive: | V-belts |
Air dryer: | No |
Retrieved from: | Professional |
Development: | Stationary |
