Thermometer aluminum pointer 100 mm (0°C/+80°C) stem 60 mm

Code: TWAL100-80-060
944 Kč / pcs 780 Kč excl. VAT
up to 14 days
Delivery to:
10.12.2024

TWALL aluminium thermometer with 100 mm pointer diameter and temperature range from 0 to 80°C. Rear version of the thermometer with 60 mm long thermowell and 1/2" threaded connection. The maximum operating pressure at the sump is 6 bar with an accuracy class of 2.0%. The technical thermometer is designed for measuring the temperature of non-aggressive media in plumbing and industry.

Detailed information

Product detailed description

TWAL aluminium thermometer TWAL100-80-060

  • We recommend measuring non-aggressive media with WIKA aluminium thermometers
  • Rear version of the thermometer is available in 63 and 100 mm diameter
  • Specifications - maximum possible measured temperature up to +200°C
  • Diameter of the sump 12 mm with 1/2" male thread connection - the sump is included in the thermometers
  • The accuracy class of these WIKA aluminium thermometers is 2.0%
  • Maximum pressure of the measuring medium can be up to 6 bar

Additional parameters

Category: Aluminium thermometers for measuring the temperature of the medium
Version: Thermometer TW
Pressure: 6 bar
Connecting: rear
Windscreen: Acrylic
Material: Aluminium
Medium: Air, Water, Non-aggressive media
Measuring member: Copper
Average: 100 mm
Temperature: 0/+80°C
Accuracy class: 2,0 %
Thread: G 1/2"
Stem length: 60 mm
The diameter of the well: 12 mm
Stem diameter: 12 mm
