Thermometer aluminum pointer 100 mm (0°C/+200°C) stem 200 mm
Code: TWAL100-200-200Product detailed description
TWAL aluminium thermometer TWAL100-200-200
- We recommend measuring non-aggressive media with WIKA aluminium thermometers
- Rear version of the thermometer is available in 63 and 100 mm diameter
- Specifications - maximum possible measured temperature up to +200°C
- Diameter of the sump 12 mm with 1/2" male thread connection - the sump is included in the thermometers
- The accuracy class of these WIKA aluminium thermometers is 2.0%
- Maximum pressure of the measuring medium can be up to 6 bar
Additional parameters
Category: | Aluminium thermometers for measuring the temperature of the medium |
---|---|
Version: | Thermometer TW |
Pressure: | 6 bar |
Connecting: | rear |
Windscreen: | Acrylic |
Material: | Aluminium |
Medium: | Air, Water, Non-aggressive media |
Measuring member: | Copper |
Average: | 100 mm |
Temperature: | 0/+200°C |
Accuracy class: | 2,0 % |
Thread: | G 1/2" |
Stem length: | 200 mm |
The diameter of the well: | 12 mm |
Stem diameter: | 12 mm |
