Shut-off valve with ventilation 10

Code: HVFF-10

Tip

Not rated

Brand: Pneumatics & Hydraulics

308 Kč –10 %

308 Kč –10 % 277 Kč / pcs 229 Kč excl. VAT

(157 pcs)

Delivery to: 20.11.2024

Shut-off valve with vent after closing for quick installation of 10 mm plastic tubing. Designed especially for measuring and control technology, automation and pneumatic compressed air distribution in industry and engineering.

Detailed information

Product detailed description

Compressed air shut-off valve with 10 mm vent

Socket couplings with reduced dimensions and weight, for quick and easy assembly of plastic tubing
Materials used : nylon, polyurethane and nickel-plated brass MS 58, threads with Teflon coating or O-ring sealing
Designed especially for automation, measuring and control technology and pneumatic compressed air distribution in industry, engineering and automotive technology.

Additional parameters

Category:	Shut-off socket plastic valve with vent
Pressure:	10 bars
A tube:	10 mm
Material:	Brass, PU
Medium:	Compressed air
Working temperature:	-10 / +60 °C
Width:	45 mm
Connection system:	Plug-in system
