    Shut-off valve without venting 6 - G1/4"

    Code: HVFSB-146
    Tip
    Not rated
    443 Kč –9 %
    Shut-off valve without venting 6 - G1/4"
    443 Kč –9 % 399 Kč / pcs 330 Kč excl. VAT
    Stock (110 pcs)
    Delivery to:
    30.12.2024

    Shut-off valve without vent on inlet pipe thread G1/4" and outlet socket coupling for 6 mm plastic tubing. Designed especially for measuring and control technology, automation and pneumatic compressed air distribution in industry and engineering.

    Detailed information

    Product detailed description

    Shut-off valve without vent G1/4" - 6 mm

    • Socket couplings with reduced dimensions and weight, for quick and easy assembly of plastic tubing
    • Materials used : nylon, polyurethane and nickel-plated brass MS 58, threads with Teflon coating or O-ring sealing
    • Designed especially for automation, measuring and control technology and pneumatic compressed air distribution in industry, engineering and automotive technology.

    Additional parameters

    Category: Shut-off socket valve side thread R
    Pressure: 10 bars
    A tube: 6 mm
    Material: Brass, PU
    Medium: Compressed air
    Working temperature: -10 / +60 °C
    Thread design: Tubular G
    Width: 40 mm
    Seals: PTFE
    Thread: G 1/4"
    Connection system: Plug-in system
