    Shut-off valve without venting 12 - G1/2"

    Code: HVFSB-1212
    Tip
    Not rated
    751 Kč –9 %
    Shut-off valve without venting 12 - G1/2"
    751 Kč –9 % 676 Kč / pcs 559 Kč excl. VAT
    Stock (63 pcs)
    Delivery to:
    01.01.2025
    Delivery offer

    Shut-off valve without vent on inlet pipe thread G1/2" and outlet socket coupling for 12 mm plastic tubing. Designed especially for measuring and control technology, automation and pneumatic compressed air distribution in industry and engineering.

    Detailed information

    Free shipping
    Free shipping
    For purchases over 5,000 CZK
    We guarantee
    We guarantee
    Extended warranty and service
    Discount voucher
    Discount voucher
    For every purchase
    Return of goods within 30 days
    Return of goods within 30 days
    Completely at our expense

    Product detailed description

    Shut-off valve without vent G1/2" - 12 mm

    • Socket couplings with reduced dimensions and weight, for quick and easy assembly of plastic tubing
    • Materials used : nylon, polyurethane and nickel-plated brass MS 58, threads with Teflon coating or O-ring sealing
    • Designed especially for automation, measuring and control technology and pneumatic compressed air distribution in industry, engineering and automotive technology.

    Additional parameters

    Category: Shut-off socket valve side thread R
    Pressure: 10 bars
    A tube: 12 mm
    Material: Brass, PU
    Medium: Compressed air
    Working temperature: -10 / +60 °C
    Thread design: Tubular G
    Width: 45 mm
    Seals: PTFE
    Thread: G 1/2"
    Connection system: Plug-in system
    Sealing ring made of Teflon PTFE DR-12TE
