Air dryer Atmos AHD 820
Code: AHD820Related products
Product detailed description
Compressed air condensation dryer AHD 820
Modern technically advanced air dryers of the AHD series, with a tradition since 1948, are among the top products in their category on the world market.
With their capacity range, advanced design and reliable solution, they are predestined for a wide range of applications in all industrial areas.
| Characteristic features of the AHD series | Limiting operating conditions |
| powerful and efficient performance in a compact size significantly reduced operating and service costs minimal maintenance requirements high reliability easy installation extremely quiet operation |
Max. inlet pressure : 16 Bar Min. inlet pressure : 3 Bar Max. inlet air temperature : +49°C Min. inlet air temperature : +4.4°C Max. ambient temperature : +43°C Min. ambient temperature : +4.4°C |
Correction factors for different operating conditions |
||||||||||||
| Temperature Supply air °C |
Working pressure (Bar) | |||||||||||
| 4 | 5 | 6 | 7 | 8 | 9 | 10 | ||||||
| 25 | 1,50 | 1,57 | 1,63 | 1,67 | 1,72 | 1,76 | 1,81 | |||||
| 30 | 1,08 | 1,13 | 1,18 | 1,22 | 1,25 | 1,29 | 1,33 | |||||
| 35 | 0,87 | 0,92 | 0,96 | 1,0 | 1,03 | 1,07 | 0,93 | |||||
| 40 | 0,72 | 0,77 | 0,81 | 0,84 | 0,87 | 0,91 | 0,93 | |||||
| 45 | 0,60 | 0,62 | 0,68 | 0,71 | 0,74 | 0,78 | 0,80 | |||||
Additional parameters
| Category: | Hankison AHD Compressed Air Dryer |
|---|---|
| Pressure: | 16 bar |
| Connecting: | 2" |
| Motor power: | 2550W |
| Mains voltage: | 230 V |
| Noise: | 66 dB(A) |
| Dimensions: | 533 x 1 291 x 811 mm |
| Weight: | 134 kg |
| Flow: | 13,666 l/min |
| Equipment:: | Bleeding by time valve |
| Refrigerant: | Refrigerant R407c |
| Pressure dew point: | +3 °C |
| Dryer type: | Condensation dryer |
Be the first who will post an article to this item!
Be the first who will post an article to this item!
Domestic Company of World-Class Quality
One of the leading companies operating in the field of compressed air, not only in the Czech Republic but also worldwide, is the domestic manufacturer ATMOS Chrást s.r.o., which is primarily known for manufacturing screw/piston compressors, screw blocks, and motor generators. The roots of the company date back to 1899, when foundries and engineering works were established in the West Bohemian village, and during the communist regime, the engineering works were part of the national enterprise Škoda Plzeň. It was at the end of this era that the company began licensed production of screw blocks and screw compressors, which over the years have gained great popularity due to their reliability. Since then, ATMOS has introduced more than 25 new types of compressors - creating ranges of mobile, locomotive, or stationary compressors that adhere to the strictest global standards while adding a touch of honest construction, which is so characteristic of ATMOS even in today's consumer era.
 |
 |
Product Range for Everyone
ATMOS continuously works on new compressors, and their features are regularly subject to technological research. Thanks to this, the company has come up with innovative ideas several times, such as when it extremely reduced the noise of stationary compressors without losing top performance parameters, leading to wide export abroad. However, ATMOS also meets the needs of private customers with smaller workshop machines alongside large companies. Another breakthrough moment was the emergence of small and compact Albert compressors, whose product line is continuously expanding and is suitable for hobby use as well. Currently, more than 60 of these types are manufactured, with output ranging from 3 to 22 kW. As the youngest, the company introduces motor generators to the market, thus filling one of the gaps in the domestic market.
