Stationary compressor A39B-2.2-150FT příkon 2,2 kW, sací výkon 393 l/min, tlak 10 bar, vzdušník 150 l, napětí 400/50 V/Hz
Code: A39B-2-2-150FTRelated products
Product detailed description
Professional piston compressor ABAC A39B-2,2-150FT
The stationary compressor from the Pro Line series with a flat air chamber is designed primarily for workshop and craft applications. The machine is equipped with a 2.2 kW electric motor and is coupled to an A39B compressor unit providing a suction capacity of 393 l/min and a pressure of 10 bar. The compressor also has the following standard equipment:
- unique belt gear cover with aerodynamically shaped grooves and aftercooler at the compressor outlet reduce the outlet air temperature by up to +35°C and ensure extreme increase in compressor lifetime
- oil reservoir equipped with oil gauge for easy reading of oil level
- automatic operation control by means of a high-end Condor pressure switch
- electric motor equipped with temperature protection
- outlet via ball valve
- pressure gauge for reading the pressure in the air tank
- 150-litre aerator with ball valve for convenient condensate drainage
- rubber bases on the airfoil reduce vibration transmission
Easy installation and maintenance thanks to service videos available via the AIRTUBE app after downloading the QR code from the pressure vessel.
We provide a standard warranty period of 2 years with the possibility of extending it to 3 years and a 10-year warranty on the rusting of the pressure vessel.
Additional parameters
| Category: | A39B single stage compressors |
|---|---|
| Warranty: | 3 years |
| Compressor type: | Piston compressor |
| Pressure: | 10 bars |
| Suction power: | 393 l/min |
| Displacement: | 283 l/min |
| Pressure vessel volume: | 150 L |
| Design of pressure vessel: | Lying down |
| Connecting: | Quick coupling DN 7.2 |
| Motor power: | 2.2 kW |
| Mains voltage: | 400/50 V/Hz |
| Speeds: | 1050 rpm |
| Number of cylinders: | 2 |
| Number of grades: | 1 degree |
| Lubrication: | Oily |
| Noise: | 93 dB - Lwa, 73 dB - Lwp(4m) |
| Dimensions: | 1 272 x 403 x 885 mm |
| Weight: | 86 kg |
| Accessories: | Pressure regulator, Quick coupler |
| Engine: | Electric |
| Soundproofed: | No |
| Drive: | V-belts |
| Air dryer: | No |
| Retrieved from: | Professional |
| Development: | Stationary |
Instalace kompresoru
Odpouštění kondenzátu
Servisní KIT kompresoru a výměna
Údržba sacího filtru
Uvedení do provozu
Výměna oleje u kompresoru
Výměna řemenu
