Parallel grippers PPC 16mm

Code: 075030
11 842 Kč –5 %
PPC chapadla pneumaticka paralelni vedeni
11 842 Kč –5 % 11 250 Kč / pcs 9 298 Kč excl. VAT
up to 14 days
Delivery to:
10.12.2024
Parallel PPC grippers with a diameter of 16 mm and a stroke of 6 mm. Design with magnet, sensor type ASC. The grippers are equipped with grooves on the body to allow direct mounting of position sensors.

Detailed information

Product detailed description

Parallel PPC grippers 16 mm

  • diameter 16 mm
  • stroke 6 mm
  • pressing force 18 N
  • connection using M5 thread
  • pressure 1,5 - 7 bar

Additional parameters

Category: Parallel grippers PPC
Pressure: 7 bar
Connecting: M5
Weight: 200 g
Materiál tělo: Aluminium
Gasket material: NBR
Inner part material: brass/steel
Max. subject length: 40 mm
Maximum number of cycles: 180/ min.
Average: 16 mm
Grip strength: 18 N
Temperature: 0/+80°C
Stroke: 6 mm
Minimální tlak: 1,5 bar
