Manometer rear 0/4 bar - 40 - 1/8"

Code: MZ01-12
186 Kč –4 %
Manometer rear 0/4 bar - 40 - 1/8"
186 Kč –4 % 177 Kč / pcs 146 Kč excl. VAT
Stock (218 pcs)
Delivery to:
25.12.2024

Plastic manometer with 40 mm diameter, G1/8" rear thread connection and 0/4 bar range. Designed for pressure measurements of non-aggressive media with lower demands on the mechanical resistance of the instrument.

Detailed information

Product detailed description

Basic plastic manometer MZ01-12

  • Materials used : plastic body, copper alloy measuring element and pointer, acrylic windscreen
  • Basic design of back-connected pressure gauges, designed for pressure measurement of non-aggressive media with lower demands on the mechanical resistance of the instrument
  • Manometers in 40 mm diameter in plastic with G1/8" thread
  • Accuracy class 2.5% with temperature range -40/+60

Additional parameters

Category: Plastic manometers MS40
Version: Plastic manometers
Connecting: rear
Windscreen: Acrylic
Material: Plastic
Medium: Air, Water
Measuring member: Brass
Average: 40 mm
Scope: 0 to 4 bar
Temperature: -40/+60°C
Accuracy class: 2,5 %
Thread: G 1/8"
Glycerinové tlumení: Ne
