Manometer side -1/0 bar - 40 - 1/8"

Manometer side -1/0 bar - 40 - 1/8"
198 Kč –5 %
198 Kč –5 % 188 Kč / pcs 155 Kč excl. VAT
Stock 247 pcs
Set up a watchdog
In store 2 pcs
External warehouse 245 pcs
We deliver to:
09.04.2025
Delivery offer

Plastic manometer with 40 mm diameter, side thread connection G1/8" and range -1/0 bar. Designed for pressure measurements of non-aggressive media with lower demands on the mechanical resistance of the instrument.

Detailed information

Code: MS01-01
Add to inquiry
Free shipping
Free shipping
For purchases over 5,000 CZK
We guarantee
We guarantee
Extended warranty and service
Discount voucher
Discount voucher
For every purchase
Return of goods within 30 days
Return of goods within 30 days
Completely at our expense

Basic plastic manometer MS01-01

  • Materials used : plastic body, copper alloy measuring element and pointer, acrylic windscreen
  • Basic design of pressure gauges with side connection, designed for pressure measurement of non-aggressive media with lower requirements for mechanical resistance of the instrument
  • Manometers in 40 mm diameter in plastic with G1/8" thread
  • Accuracy class 2.5% with temperature range -40/+60
Product is included in the following categories: Measuring technology Manometers Manometers plastic Pressure gauges MS40

Technical parameters

Category: Plastic manometers MS40
Version: Plastic manometers
Connecting: party
Windscreen: Acrylic
Material: Plastic
Medium: Air, Water
Measuring member: Brass
Average: 40 mm
Scope: -1 to 0 bar
Temperature: -40/+60°C
Accuracy class: 2,5 %
Thread: G 1/8"
Glycerin damping: No
