    Side manometer 0/250 bar - 100 mm - M20*1.5

    Code: MS07-21
    Not rated
    441 Kč –4 %
    Side manometer 0/250 bar - 100 mm - M20*1.5
    441 Kč –4 % 419 Kč / pcs 346 Kč excl. VAT
    Stock (49 pcs)
    Delivery to:
    30.09.2024

    Plastic manometer with 100 mm diameter gauge with side connection via M20*1.5 metric thread for pressure measurement with a range of 0 to 250 bar. Designed for pressure measurements of non-aggressive media with lower demands on the mechanical resistance of the instrument. Accuracy class 1.6%.

    Detailed information

    Related products

    Manometer cover GOMB-100
    Manometer cover GOMB-100
    Stock (10 pcs)
    393 Kč excl. VAT
    476 Kč

    The diameter of the cover is 100 mm. It is suitable for applications with higher demands on instrument life.

    Code: GOMB-100
    Shut-off pressure gauge valve VM-400-M20-O
    Shut-off pressure gauge valve VM-400-M20-O
    up to 14 days
    1 764 Kč excl. VAT
    2 134 Kč

    The working pressure is 400 bar. Connection is M20 × 1.5. The valve body is made of steel.

    Code: VM-400-M20-O
    Test pressure gauge valve VZ-400-M20-O
    Test pressure gauge valve VZ-400-M20-O
    up to 14 days
    1 931 Kč excl. VAT
    2 336 Kč

    The working pressure is 400 bar. Connection is M20 × 1.5. The valve body is made of steel.

    Code: VZ-400-M20-O
    Pressure gauge connection socket PTN-M20M20L
    262 Kč –2 %
    Pressure gauge connection socket PTN-M20M20L
    Stock (6 pcs)
    212 Kč excl. VAT
    256 Kč

    The connection is equipped with two internal threads M20 × 1.5 and M20 × 1.5 left-hand.

    Code: PTN-M20M20L
    Sealing ring TP-M20
    Sealing ring TP-M20
    Stock (7 pcs)
    9 Kč excl. VAT
    11 Kč

    Sealing ring made of aluminium for thread M20 × 1.5; G 1/2".

    Code: TP-M20
    Show all related products Previous product Next product

    Product detailed description

    Basic plastic manometer MS07-21

    • Materials used : plastic body, copper alloy measuring element and pointer, acrylic windscreen
    • Basic design of pressure gauges with side connection, designed for pressure measurement of non-aggressive media with lower requirements for mechanical resistance of the instrument
    • Manometers with diameter 100 mm in plastic with thread M20*1,5
    • Accuracy class 1.6% with temperature range -40/+60

    Additional parameters

    Category: Plastic manometers MS100M
    Version: Plastic manometers
    Connecting: party
    Windscreen: Acrylic
    Material: Plastic
    Medium: Air, Water
    Measuring member: Brass
    Average: 100 mm
    Scope: 0 to 250 bar
    Temperature: -40/+60°C
    Accuracy class: 1,6 %
    Thread: M20 x 1.5
    Glycerinové tlumení: Ne
