    Home / Fasteners / Plastic socket couplings; socket blue / L-couplings; external thread R / L-coupling 16 - R1/2"

    L-coupling 16 - R1/2"

    Code: PL-1216
    Tip
    Not rated
    278 Kč –10 %
    L-coupling 16 - R1/2"
    278 Kč –10 % 250 Kč / pcs 207 Kč excl. VAT
    Stock (219 pcs)
    Delivery to:
    25.12.2024

    Socket coupling in plastic corner design with 1/2" male tapered thread. Quick and easy installation of plastic tubing with 16 mm outer diameter. Designed especially for automation, pneumatic compressed air distribution in industry, engineering and automotive technology. Maximum operating temperature in the range -10/60°C at a maximum medium pressure of 10 bar.

    Detailed information

    Related products

    Black polyurethane hose 16/11 mm
    Tip
    193 Kč –9 %
    Black polyurethane hose 16/11 mm
    Stock (664 m)
    144 Kč excl. VAT
    174 Kč

    PUJ polyurethane tubing in black 16/11 mm, especially suitable for mechanically stressed lines, excellent flexibility. High resistance to oxygen, ozone, vibration and aging. Use...

    Code: PUJ1611S
    Polyurethane tube red 16/11 mm
    Tip
    193 Kč –9 %
    Polyurethane tube red 16/11 mm
    Stock (169 m)
    144 Kč excl. VAT
    174 Kč

    Polyurethane PUJ tubing in red 16/11 mm, especially suitable for mechanically stressed lines, excellent flexibility. High resistance to oxygen, ozone, vibration and aging. Use...

    Code: PUJ1611R
    Clear polyurethane tubing 16/11 mm
    Tip
    193 Kč –9 %
    Clear polyurethane tubing 16/11 mm
    Stock (193 m)
    144 Kč excl. VAT
    174 Kč

    Polyurethane PUJ tubing in neutral transparent 16/11 mm design, particularly suitable for mechanically stressed lines, excellent flexibility. High resistance to oxygen, ozone,...

    Code: PUJ1611N
    Polyurethane tube blue 16/11 mm
    Tip
    193 Kč –9 %
    Polyurethane tube blue 16/11 mm
    up to 14 days
    144 Kč excl. VAT
    174 Kč

    Polyurethane PUJ tubing in blue 16/11 mm, especially suitable for mechanically stressed lines, excellent flexibility. High resistance to oxygen, ozone, vibration and aging. Use...

    Code: PUJ1611B
    Polyurethane hose green 16/11 mm
    Tip
    193 Kč –9 %
    Polyurethane hose green 16/11 mm
    Stock (258 m)
    144 Kč excl. VAT
    174 Kč

    Green PUJ polyurethane tubing 16/11 mm, especially suitable for mechanically stressed lines, excellent flexibility. High resistance to oxygen, ozone, vibration and aging. Use...

    Code: PUJ1611G
    Yellow polyurethane tube 16/11 mm
    Tip
    193 Kč –9 %
    Yellow polyurethane tube 16/11 mm
    Stock (>1000 m)
    144 Kč excl. VAT
    174 Kč

    Polyurethane PUJ tubing in yellow 16/11 mm suitable especially for mechanically stressed lines, excellent flexibility. High resistance to oxygen, ozone, vibration and aging. Use...

    Code: PUJ1611Y
    Show all related products Previous product Next product

    Product detailed description

    Corner fitting with external tapered thread 16 - R1/2"
    in plastic design

    • Socket couplings with reduced dimensions and weight, for quick and easy assembly of plastic tubing
    • Materials used : nylon, polyurethane and nickel-plated brass MS 58, threads with Teflon coating or O-ring sealing
    • Designed especially for automation, measuring and control technology and pneumatic compressed air distribution in industry, engineering and automotive technology.

    Additional parameters

    Category: L-couplings with male thread R
    Pressure: 10 bars
    A tube: 16 mm
    Material: Brass, PU
    Medium: Compressed air
    Working temperature: -10 / +60 °C
    Thread design: Kuželový R
    SW (key): 24
    Width: 56 mm
    Seals: PTFE
    Thread: R 1/2"
    Shape: Corner couplings
    Connection system: Plug-in system
