Ball valve V101 with double-acting drive DA - 2"
Code: V101-20DAProduct detailed description
Ball valves V101 with air actuator V101-20DA
- Ball valve assembly with internal threads - type V101 and OMAL pneumatic actuator (double-acting DA or single-acting SR version)
- Drive control pressure of at least 5.5 bar
- For sealing of pipelines of non-aggressive media (water, air, etc.) in industry
Additional parameters
| Category: | V101 straight taps with pneumatic actuator |
|---|---|
| Pressure: | 32 bar |
| Connecting: | Thread |
| Material: | Brass |
| Medium: | Air, Water |
| Standard: | ISO 5211 |
| Thread design: | Internal |
| Brightness DN: | 50 |
| Seals: | PTFE |
| Drive type: | Double acting pneumatic drive |
| Thread: | G 2" |
| Controls: | Pneumatic drive |
| Design of fittings: | Direct, Two-piece |
Be the first who will post an article to this item!
Be the first who will post an article to this item!
A Company with a Clear Goal and ValuesItaly's leading role in air production could be confirmed by the company Omal Automation. It is one of the leading Italian companies specializing in the production of compressed air and its applications. This primarily involves the manufacture of various cocks, valves, and fittings. It is a company that approaches its work with responsibility and a clearly defined ethical code, focused primarily on providing the best quality to end customers. Its main values include dedication, respect, and a sense of duty. |
 |
 |
A Bet on the FutureThe company first engaged in the compressed air sector in the early 1980s, when the foundation of a family business producing ball valves was established. The vision of imminent automation and harnessing the potential of this sector soon materialized, and the company has been growing year after year. Investment in a team of technicians and engineers proved to be more than useful, and in 1987, the company moved to larger premises for the first time. This happened twice more in the following years - in 2008 and finally in 2016. |
For more than forty years, Omal's products have become a well-known name, gaining the favor of thousands of satisfied customers. However, one of the company's ongoing goals remains innovation in the field and the design of new constructions. Omal Automation is known primarily for the production of cocks and fittings, which we completely trust from previous experience, and therefore the entire offered assortment can be found below.
