MSM 8 mm single-acting circular cylinder

Code: 8/10MSM 8/25MSM 8/50MSM Choose variant
1 872 Kč 1 959 Kč 2 057 Kč from 1 872 Kč –5 %
MSM 8 mm single-acting circular cylinder
1 872 Kč 1 959 Kč 2 057 Kč from 1 872 Kč –5 % 1 778 Kč / pcs 1 861 Kč / pcs 1 954 Kč / pcs from 1 778 Kč / pcs 1 469 Kč excl. VAT 1 538 Kč excl. VAT 1 615 Kč excl. VAT from 1 469 Kč excl. VAT
up to 14 days up to 14 days up to 14 days Choose variant
Cylinder stroke
Chosen variant is not available. Reset selected parameters.
Delivery to:
10.12.2024 10.12.2024 10.12.2024 Choose variant

Single-acting circular cylinder of 8 mm diameter with magnet. Compliant with ISO 6432 standards. Pneumatic cylinder including nuts on threads and characterized by perfect tightness due to pressing of individual parts. Selectable piston stroke from 10 to 50 mm.

Detailed information

Product detailed description

Single acting circular roller with magnet - 8/...MSM

  • diameter 8 mm
  • strokes 10, 25 , 50 mm
  • connection using M5 thread
  • pressure 10 bar
  • made of aluminium, stainless steel and brass

Jednočinné kruhové pneumatické válce MS

Additional parameters

Category: MS and MSM single-acting circular cylinders
Version: Single acting cylinders
Pressure: 10 bars
Connecting: M5
Magnet: with a magnet
Piston rod material: Stainless steel AISI303
Piston material: Brass
Profile material: Stainless steel AISI304
Lid material: Aluminium
Average: 8 mm
Temperature: -30/+80°C
Seals: PU
Cylinder thrust: 20 N
Cylinder type: Circular
Stroke selection: 10, 25, 50 mm
Connecting rod thread: M4
