MSM single-acting circular cylinder 12 mm

Code: 12/10MSM 12/25MSM 12/50MSM Choose variant
1 574 Kč 1 606 Kč 1 637 Kč from 1 574 Kč –4 %
MSM single-acting circular cylinder 12 mm
1 574 Kč 1 606 Kč 1 637 Kč from 1 574 Kč –4 % 1 496 Kč / pcs 1 526 Kč / pcs 1 556 Kč / pcs from 1 496 Kč / pcs 1 236 Kč excl. VAT 1 261 Kč excl. VAT 1 286 Kč excl. VAT from 1 236 Kč excl. VAT
up to 14 days up to 14 days up to 14 days Choose variant
Cylinder stroke
Chosen variant is not available. Reset selected parameters.
Delivery to:
21.01.2025 21.01.2025 21.01.2025 Choose variant
Delivery offer

Single-acting circular cylinder with a diameter of 12 mm with magnet. Compliant with ISO 6432 standards. Pneumatic cylinder including nuts on threads and characterized by perfect tightness due to pressing of individual parts. Selectable piston stroke from 10 to 50 mm.

Detailed information

Free shipping
Free shipping
For purchases over 5,000 CZK
We guarantee
We guarantee
Extended warranty and service
Discount voucher
Discount voucher
For every purchase
Return of goods within 30 days
Return of goods within 30 days
Completely at our expense

Product detailed description

Single acting circular roller with magnet - 12/...MSM

  • diameter 12 mm
  • strokes 10, 25 , 50 mm
  • connection using M5 thread
  • pressure 10 bar
  • made of aluminium, stainless steel and brass

Jednočinné kruhové pneumatické válce MS

Additional parameters

Category: MS and MSM single-acting circular cylinders
Version: Single acting cylinders
Pressure: 10 bars
Connecting: M5
Magnet: with a magnet
Piston rod material: Stainless steel AISI303
Piston material: Brass
Profile material: Stainless steel AISI304
Lid material: Aluminium
Average: 12 mm
Temperature: -30/+80°C
Seals: PU
Cylinder thrust: 50 N
Cylinder type: Circular
Stroke selection: 10, 25, 50 mm
Connecting rod thread: M6
