    Single-acting circular cylinder MS 25 mm

    Code: 25/10MS 25/25MS 25/50MS Choose variant
    Not rated
    Brand: A.P.I.
    1 808 Kč 1 867 Kč 1 953 Kč from 1 808 Kč –5 %
    Single-acting circular cylinder MS 25 mm
    1 808 Kč 1 867 Kč 1 953 Kč from 1 808 Kč –5 % 1 717 Kč / pcs 1 773 Kč / pcs 1 855 Kč / pcs from 1 717 Kč / pcs 1 419 Kč excl. VAT 1 465 Kč excl. VAT 1 533 Kč excl. VAT from 1 419 Kč excl. VAT
    up to 14 days Stock (1 pcs) up to 14 days Choose variant
    Cylinder stroke
    Chosen variant is not available. Reset selected parameters.
    Delivery to:
    21.01.2025 02.01.2025 21.01.2025 Choose variant
    Delivery offer

    Single-acting circular cylinder with a diameter of 25 mm without magnet. Compliant with ISO 6432 standards. Pneumatic cylinder including nuts on threads and characterized by perfect tightness due to pressing of individual parts. Selectable piston stroke from 10 to 50 mm.

    Detailed information

    Free shipping
    Free shipping
    For purchases over 5,000 CZK
    We guarantee
    We guarantee
    Extended warranty and service
    Discount voucher
    Discount voucher
    For every purchase
    Return of goods within 30 days
    Return of goods within 30 days
    Completely at our expense

    Related products

    Position sensors ASV1C525
    Original parts
    784 Kč –4 %
    Position sensors ASV1C525
    Stock (6 pcs)
    616 Kč excl. VAT
    745 Kč

    Cylinder end position sensor with 2.5 m fixed cable connection. Reed relay sensing, for 5-240V AC and DC voltages. Red LED signaling.

    Code: 070946
    AFM25 sensor mounts
    Original parts
    231 Kč –4 %
    AFM25 sensor mounts
    up to 14 days
    182 Kč excl. VAT
    220 Kč

    Handles for position sensors for circular pneumatic cylinders and for cylinders according to ISO 6432 with a diameter of 25 mm in automation.

    Code: 072906
    FFISO 10 piston rod fork
    Original parts
    147 Kč –5 %
    FFISO 10 piston rod fork
    Stock (12 pcs)
    115 Kč excl. VAT
    139 Kč

    Piston rod fork according to ISO 8140 type FFISO for cylinders 25 - 32mm with connection thread M10x1,25

    Code: 041004
    RF kloubova hlavice cilinders api vzduch tlak valce pneumaticke
    Original parts
    231 Kč –4 %
    Joint heads RF - M10 × 1.25
    Stock (4 pcs)
    182 Kč excl. VAT
    220 Kč

    Articulated sockets for pneumatic cylinder on piston rod according to 8139 and DIN 648-K type RF for cylinders 25 - 32 mm with connection thread M10 × 1.25. Supplied in...

    Code: 041554
    Flexible couplings GB 040
    Original parts
    780 Kč –5 %
    Flexible couplings GB 040
    up to 14 days
    612 Kč excl. VAT
    741 Kč

    Flexible couplings type GB for cylinders 25 - 32 mm with connection thread M10x1,25. Supplied in galvanized steel.

    Code: 041704
    Axial joint couplings RBI 10
    Original parts
    2 066 Kč –4 %
    Axial joint couplings RBI 10
    Stock (2 pcs)
    1 622 Kč excl. VAT
    1 963 Kč

    Axial joint couplings type RBI for cylinders with diameter 25 - 32 mm with connection thread M10x1,25. Supplied in special zinc alloy.

    Code: 041604
    Angular axial joint couplings RBL 10
    Original parts
    2 066 Kč –4 %
    Angular axial joint couplings RBL 10
    up to 14 days
    1 622 Kč excl. VAT
    1 963 Kč

    Angular axial joint couplings type RBL for cylinders with diameter 25 - 32 mm with connection thread M10x1,25. Supplied in special zinc alloy.

    Code: 041654
    cf uchyty valcu
    Original parts
    210 Kč –99 %
    Rear fork with CF 20-25 mm pivot
    up to 14 days
    1 Kč excl. VAT
    1 Kč

    Rear forks with pin type CF designed for cylinders according to ISO 6432 with a diameter of 20 to 25 mm. Made of steel.

    Code: 040043
    f pruruba
    Original parts
    204 Kč –4 %
    Front flanges F 20-25 mm
    Stock (4 pcs)
    160 Kč excl. VAT
    194 Kč

    Type F face flanges designed for cylinders according to ISO 6432 with a diameter of 20 to 25 mm. Made of steel.

    Code: 040003
    p patky valce
    Original parts
    156 Kč –5 %
    Foot attachment P 20-25 mm
    Stock (5 pcs)
    122 Kč excl. VAT
    148 Kč

    P-type foot mounting for cylinders according to ISO 6432 with a diameter of 20 to 25 mm. Made of steel.

    Code: 040023
    Angular throttle valve 6 - R1/8"
    Tip
    202 Kč –10 %
    Angular throttle valve 6 - R1/8"
    Stock (5 pcs)
    150 Kč excl. VAT
    181 Kč

    Socket couplings with reduced dimensions and weight, for quick and easy assembly of plastic tubing Designed especially for automation, measuring and control technology and...

    Code: SCO-186
    Angular throttle valve 4 - R1/8"
    Tip
    188 Kč –10 %
    Angular throttle valve 4 - R1/8"
    Stock (320 pcs)
    140 Kč excl. VAT
    169 Kč

    Socket couplings with reduced dimensions and weight, for quick and easy assembly of plastic tubing Designed especially for automation, measuring and control technology and...

    Code: SCO-184
    Angular throttle valve 8 - R1/8"
    Tip
    201 Kč –9 %
    Angular throttle valve 8 - R1/8"
    Stock (248 pcs)
    150 Kč excl. VAT
    181 Kč

    Socket couplings with reduced dimensions and weight, for quick and easy assembly of plastic tubing Designed especially for automation, measuring and control technology and...

    Code: SCO-188
    Angular throttle valve 10 - R1/8"
    Tip
    288 Kč –10 %
    Angular throttle valve 10 - R1/8"
    Stock (229 pcs)
    214 Kč excl. VAT
    259 Kč

    Socket couplings with reduced dimensions and weight, for quick and easy assembly of plastic tubing Designed especially for automation, measuring and control technology and...

    Code: SCO-1810
    Show all related products Previous product Next product

    Product detailed description

    Single-acting circular cylinder - 25/...MS

    • diameter 25 mm
    • strokes 10, 25 , 50 mm
    • connection using M5 thread
    • pressure 10 bar
    • made of aluminium, stainless steel and brass

    Jednočinné kruhové pneumatické válce MS

    Additional parameters

    Category: MS and MSM single-acting circular cylinders
    Version: Single acting cylinders
    Pressure: 10 bars
    Connecting: 1/8"
    Magnet: without magnet
    Piston rod material: Stainless steel AISI303
    Piston material: Brass
    Profile material: Stainless steel AISI304
    Lid material: Aluminium
    Average: 25 mm
    Temperature: -30/+80°C
    Seals: PU
    Cylinder thrust: 250 N
    Cylinder type: Circular
    Stroke selection: 10, 25, 50 mm
    Connecting rod thread: M10 x 1.25
