Single-acting circular cylinder MS 10 mm

Code: 10/10MS 10/25MS 10/50MS Choose variant
1 827 Kč 1 919 Kč 2 017 Kč from 1 827 Kč –5 %
Single-acting circular cylinder MS 10 mm
1 827 Kč 1 919 Kč 2 017 Kč from 1 827 Kč –5 % 1 735 Kč / pcs 1 823 Kč / pcs 1 916 Kč / pcs from 1 735 Kč / pcs 1 434 Kč excl. VAT 1 507 Kč excl. VAT 1 583 Kč excl. VAT from 1 434 Kč excl. VAT
up to 14 days up to 14 days up to 14 days Choose variant
Cylinder stroke
Chosen variant is not available. Reset selected parameters.
Delivery to:
18.10.2024 18.10.2024 18.10.2024 Choose variant

Single-acting circular cylinder with a diameter of 10 mm without magnet. Compliant with ISO 6432 standards. Pneumatic cylinder including nuts on threads and characterized by perfect tightness due to pressing of individual parts. Selectable piston stroke from 10 to 50 mm.

Detailed information

Product detailed description

Single-acting circular cylinder - 10/...MS

  • diameter 10 mm
  • strokes 10, 25 , 50 mm
  • connection using M5 thread
  • pressure 10 bar
  • made of aluminium, stainless steel and brass

Jednočinné kruhové pneumatické válce MS

Additional parameters

Category: MS and MSM single-acting circular cylinders
Version: Single acting cylinders
Pressure: 10 bars
Connecting: M5
Magnet: without magnet
Piston rod material: Stainless steel AISI303
Piston material: Brass
Profile material: Stainless steel AISI304
Lid material: Aluminium
Average: 10 mm
Temperature: -30/+80°C
Seals: PU
Cylinder thrust: 35 N
Cylinder type: Circular
Stroke selection: 10, 25, 50 mm
Connecting rod thread: M4

Be the first who will post an article to this item!

Do not fill out this field:

Be the first who will post an article to this item!

Do not fill out this field:

Advanced Pneumatic Industries - Pneumatic Components for Automation Technology

Rich Experience Complements a Wide Range

One of the traditional suppliers of pneumatic components is the company API (Advanced Pneumatic Industries), which was established in the late 1980s near Milan, Italy. More than three decades of experience have helped API to perfect the production of all pneumatic components. At the turn of the new millennium, the company invested a significant amount in its own development and thus began its own production of valves and cylinders. Since 2007, the API catalog has included the widest possible range in its field, and products are soon shipped worldwide. Currently, the company offers manufacture and assembly of valves, cylinders, and mounting accessories not only from aluminum and steel, but also stainless steel materials in its offerings. Beyond the standard offering, API stands out with the option of supplying solutions such as valve terminal assemblies or special ATEX versions.

api-provozovna
API

Quality Certificate at a Good Price

For the entire range of the Italian company, it holds true that customers can rely on it. These are products with good technical properties, while the price remains within reasonable limits. These words are confirmed by hundreds of our satisfied customers (mainly from the industrial sector), for whom API is the preferred brand. Beside words, however, the reliability of the products is demonstrated by rigorous quality systems such as ISO 9001, CISQ, ICIM, or IQNet, whose certificates the products proudly bear. The supplier program currently offers pneumatic cylinders, grippers, rotary actuators, accessories for cylinders and mounting brackets, electromagnetic, pneumatic, mechanical and manual valves, air treatment devices, fittings, couplings, and hoses.

The offered range from API is brought to you by our company Compressors air technology here.
