Hoses and accessories for air, water and other media, Page 78
Product sorting
List of products
Azure PA11 polyamide tube 8/6 mm, light blue for a second supply next to the blue one. Working pressure 19 bar, burst pressure 57 bar.
Black PA11 polyamide tube 10/7 mm for machine and line pipework where the line should blend into the structure. It withstands a working pressure of 24 bar.
Black PA11 Rilsan tube 12/10 mm, thin-walled and unobtrusive. For feed branches of machines with higher consumption, working pressure 12 bar.
Black PA11 polyamide tube 12/9 mm for machine and line feed branches. Unobtrusive colour, 1.5 mm wall, working pressure 19 bar.
Black PA11 polyamide tube 7/5 mm for repairs and lines on a machine. Working pressure 22 bar, sold by the metre or as a full 100 m roll.
Black PA11 polyamide tube 8/5 mm for durable lines on machines. Working pressure 31 bar, −40 to +80 °C, sold by the metre.
Blue PA11 polyamide tube 10/6.5 mm with a 1.75 mm wall and a working pressure of 28 bar. A full roll is 100 m, and we also sell it by the metre.
Blue PA11 polyamide tube 10/7 mm with a balanced ratio of flow and pressure. With a 1.5 mm wall, it has a working pressure of 24 bar.
Blue PA11 polyamide tube 12/9 mm for compressed air feed branches. Working pressure 19 bar, still 8.9 bar at 80 °C.
Blue PA11 polyamide tube 6/4 mm for pneumatic valves and cylinders. Working pressure 27 bar at 20 °C, sold by the metre.
Clear PA11 tube 10/7 mm with a working pressure of 24 bar. The transparent 1.5 mm wall resists moisture, oils and chemicals.
Clear PA11 polyamide tube 4/3 mm with a thin transparent 0.5 mm wall for checking the medium. Working pressure 19 bar, burst pressure 57 bar.
Clear PA11 polyamide tube 7/5 mm with a transparent 1 mm wall in which you can see condensate. Working pressure 22 bar, minimum bend radius 38 mm.
Clear PA11 tube 8/4 mm with a thick 2 mm wall. Working pressure 44 bar, the highest in the series, and a transparent wall for checking the medium.
Green PA11 polyamide tube 10/6 mm for telling another circuit apart. The thick 2 mm wall carries a working pressure of 33 bar.
PA11 tube 10/6.5 mm in green for another circuit on a machine. 1.75 mm wall, 28 bar, working temperature −40 to +80 °C.
Green PA11 Rilsan tube 12/9 mm for telling another circuit on a machine apart. Hard polyamide with a 1.5 mm wall, working pressure 19 bar.
Green PA11 Rilsan tube 4/2.5 mm with a working pressure of 31 bar. A colour for one more circuit and a size for standard control lines.
Green PA11 polyamide tube 5/3 mm that lets you distinguish one more circuit on a machine. Working pressure 33 bar, hardness 63 Shore D.
Red PA11 polyamide tube 10/6.5 mm for marking an important branch. Working pressure 28 bar, minimum bend radius 60 mm.
Red PA11 polyamide tube 10/7 mm that clearly sets an important branch apart. Working pressure 24 bar, full roll 100 m.
Red PA11 polyamide tube 12/10 mm for a clearly marked high-flow supply line. Thin-walled, working pressure 12 bar, 100 m roll.
Red PA11 polyamide tube 12/9 mm for clearly marking an important feed branch. Working pressure 19 bar, burst pressure 57 bar.
Red PA11 Rilsan tube 14/10 mm for marking the main pressure branch of a machine or line. Thick 2 mm wall, working pressure 22 bar.
Red PA11 Rilsan tube 4/2.5 mm for highlighting an important branch. Working pressure 31 bar, burst pressure 92 bar, −40 to +80 °C.
Red PA11 tube 4/2.7 mm for clearly marking an important control branch on a machine. Working pressure 26 bar, burst pressure 78 bar.
Red rigid PA11 polyamide tube 5/3 mm for marking a branch with a special role. It withstands 33 bar and temperatures from −40 to +80 °C.
Highly visible yellow PA11 tube 10/6 mm with a working pressure of 33 bar. It works from −40 to +80 °C and stands out even in a dark corner of a hall.
Yellow PA11 polyamide tube 10/6.5 mm that you will spot on a machine straight away. Working pressure 28 bar, sold by the metre.
Yellow PA11 tube 10/7 mm in a striking colour that makes the line easy to trace. 1.5 mm wall, working pressure 24 bar.
Yellow PA11 tube 10/8 mm that combines a striking colour with the largest inner diameter of the 10 mm tubes. Working pressure 15 bar, full roll 100 m.
Yellow PA11 Rilsan tube 12/9 mm that can be seen on a machine even from further away. Hard polyamide with a 1.5 mm wall and a pressure of 19 bar.
Yellow PA11 polyamide tube 14/10 mm, a heavy supply line visible from a distance. 2 mm wall, working pressure 22 bar, −40 to +80 °C.
Yellow PA11 polyamide tube 4/2.5 mm with a working pressure of 31 bar and a 0.75 mm wall. A striking colour you will not miss on a machine.
The hose is designed for hydraulic oils, antifreeze, water, hot oils and compressed air in 19.1/12 mm blue. Special pressure hoses for easy assembly without the need for hose...
Plastic polyurethane hose 6/4 mm made of Elastollan 1198. White in colour yet transparent for better UV resistance. Operating temperature -40/+60 °C with hardness 49-55 °Sh....
Plastic polyurethane hose 4/2,5 mm made of Elastollan 1198. Red in colour yet transparent for better UV resistance. Operating temperature -40/+60 °C with hardness 49-55 °Sh....
Plastic polyurethane hose 6/4 mm made of Elastollan 1198. Red in colour yet transparent for better UV resistance. Operating temperature -40/+60 °C with hardness 49-55 °Sh....
Plastic polyurethane hose 8/5,5 mm made of Elastollan 1198. Red in colour yet transparent for better UV resistance. Operating temperature -40/+60 °C with hardness 49-55 °Sh....
Plastic polyurethane hose 8/5,5 mm made of Elastollan 1198. Blue in colour yet transparent for better UV resistance. Operating temperature -40/+60 °C with hardness 49-55 °Sh....
